BVA Hydraulics – 55 Tons Capacity, Custom Electric-Hydraulic Press

Spec Sheet
Inquire About This Product

Add to Wishlist
Categories: ,
Description

BVA Hydraulics – 55 Tons Capacity, Custom Electric-Hydraulic Press

  • 110,000 Lbs. Maximum Force.
  • Double acting (Advance-Retract).
  • 20.00″ Stroke/travel.
  • Collar thread flange mount.
  • 42″ Horizontal opening.
  • 3 position, adjustable lower bed.

BVA Hydraulics PE50S4L05A Electric Hydraulic Pump

  • 115 VAC, 60 Hz., 1 Ph., 1½ Hp.
  • 3-Position (Advance-Hold-Retract) solenoid-operated directional valve.
  • 10′ Handheld, momentary push button pendant valve control.
  • High flow, 2-stage design.
  • Internal relief valve – 10,000 p.s.i. maximum pressure.
  • 5 Gallons oil reservoir.
  • High flow, 2-stage design.
  • 476 cu.” of oil per minute from 0 – 700 p.s.i. (1st Stage).
  • 61 cu.” of oil per minute from 701 – 10,000 p.s.i. (2nd Stage).

BVA Hydraulics HD5520 Double Acting, Hydraulic Cylinder

  • 110,000 Lbs. Force @10,000 p.s.i. (Maximum Pressure).
  • Double acting (Advance-Retract).
  • 20.00″ Stroke/travel.
  • Collar thread mount.
  • All BVA Hydraulics cylinders meet or exceed ASMEB30.1 design, assembly, safety & testing requirements.
