SPX Power Team High Pressure Electric Pump

Spec Sheet
Inquire About This Product

Add to Wishlist
Category:
Description

Power Team PE462S Electric Hydraulic Pump

  • 115 VAC, 1 ph., 60 Hz., 1½ Hp., induction motor.
  • 2.5 gallon reservoir.
  • Solenoid operated directional valve.
  • 25′ Hand held push button pendant control.
  • 500 cu.” oil per minute @100 p.s.i. (1st Stage).
  • 46 cu.” of oil per minute @10,000 p.s.i. (2nd Stage).

Shown equipped with Power Team 9633 in line pressure relief valve.
