BVA Hydraulics 10,000 PSI Electric Hydraulic Pumps

BVA Hydraulics PE Series of 10,000 psi, single-phase electric hydraulic pumps offer an endless variety of build options.  Manually operated and solenoid-operated directional valves provide a solution for use with 10,000 psi single-acting spring return, lock-nut style, through-hole, load return, and double-acting cylinders.  Pressure switch control, foot-operated solenoid valve operation, handheld motor control, solenoid valve pendant, wireless control, and reservoir volumes ranging from 1 – 25 gallons are easily defined in the build matrix.

For expert technical advice with standard and custom models or to discuss your project details, please reach out to us.  Serving as both a Factory Authorized Stocking Distributor as well as a Factory Authorized Warranty Service Center for all BVA Hydraulics products, Buffalo Hydraulic will be glad to help guide you through your project from start to finish!

Spec Sheet
Inquire About This Product

Add to Wishlist
Categories: ,
Description

BVA Hydraulics PE50W4N05A Electric Hydraulic Pumps

  • 120 VAC, 1 Ph., 60 Hz., 1.5 Hp.
  • 3-Position (Advance-Hold-Retract) Manually operated directional valve.
  • 10′ 24 VDC handheld motor control pendant.
  • Internal 10,000 psi relief valve.
  • 5 Gallons oil reservoir with sight gauge.
  • 80 dBA.
  • 100% Duty cycle, NEMA 5 enclosure TEFC electric motors.
  • All PE30, PE40, and PE 50 Series electric hydraulic pumps are designed to start under full load.
  • 476 cu.” Of oil per minute from 0 – 700 p.s.i. (1st Stage).
  • 61 cu.” Of oil per minute from 701 – 10,000 p.s.i. (2nd Stage).
