BVA Hydraulics Low Profile HL1002, 100 Tons Capacity Hydraulic Jacking Cylinder

BVA Hydraulics HL Series of 10,000 psi hydraulic cylinders offer a low height, high tonnage solution with a capacity range from 10-100 tons through six standard models.

Spec Sheet
Inquire About This Product

Add to Wishlist
Categories: ,
Description

BVA Hydraulics Low Profile HL1002, 100 Tons Capacity Hydraulic Jacking Cylinder

  • 98.2 Tons capacity @10,000 p.s.i. (Maximum Pressure).
  • 5.55″ Collapsed height.
  • 2.24″ Stroke/travel.
  • Single acting, spring return.
  • 45.4 Lbs.
