BVA Hydraulics 25 Tons Capacity, Custom Design, Electric-Hydraulic Press

BVA Hydraulics IAP, IEP, and IMP Series of Hydraulic Presses are offered through (19) standard models with a broad range of 25-100 tons of pressing force.

IA Models include an air/hydraulic pump.

IEP Models are supplied with an electric/hydraulic pump.

IMP Models include a two-stage, hand/hydraulic pump.

If your pressing requirements require something different from the standard models, please let us know – We’ll be glad to help further meet your specifications.

Spec Sheet
Inquire About This Product

Add to Wishlist
Categories: ,
Description

BVA Hydraulics 25 Tons Capacity, Custom Design, Electric-Hydraulic Press

  • 50,000 Pounds/Force, pressing capacity.
  • 20.00″ Vertical opening.
  • 28.00″ Horizontal opening.
  • Inverted, single-acting, spring return 25 tons capacity hydraulic cylinder.
  • 14.25″ Stroke/travel.
  • Hard chrome plunger with 1.50″, 16 female thread.
  • High volume 115 VAC, 1.5 Hp. electric/hydraulic pump.
  • 2-Stage design
  • 476 cu.” of oil per minute flow rate – 1st stage.
  • 61 cu.” of oil per minute flow rate at 10,000 psi – 2nd stage.
  • 3/way, 3/position (Advance-Hold-Retract) manually operated directional valve.
  • 10′ Handheld, momentary, push-button motor control pendant.
  • 3 Gallon’s oil reservoir.
  • 0-50,000 lbs force, NIST Certified, glycerin-filled pressure gauge.
