SPX Power Team PE462 Electric Hydraulic Pump.

• 10,000 psi maximum pressure.
• 115/230 VAC, 1 Ph., 60 Hz. (220 vac, 50 Hz. optional).
• High flow, two speed design.
• 450 cu.” of oil per minute – 1st stage flow rate.
• 46 cu.” of oil per minute 2nd stage flow rate.
• 3/way and 4/way directional valve options in manually and solenoid operation.
• 10′ hand held motor control pendants on all manual valve models.
• 10 – 25′ hand held pendant control on solenoid valve models.
• 24 volt controls on all pendant circuitry.
• 71 – 81 dBA operation and starts under full load.
• All metal, 590 cu.” oil reservoir standard design throughout.

From dump design, to 3/way and 4/way operation, the SPX Power Team PE46 Series of electric hydraulic pumps offer a rugged and reliable design for 10,000 psi applications that require less than 590 cu.” of oil volume.

This family of pumps is also custom offered in 12 vdc for remote operation from service vehicles.
