SPX Power Team, RD Series, Hydraulic Cylinders
SPX Power Team, RD Series, High Tonnage, Double Acting, Hydraulic Cylinders.
- 10,000 p.s.i. Maximum operating pressure.
- 10 – 497 Tons capacity – models.
- Optional swivel load cap, tilt saddles available on 10, 25, 55, 100, 150 and 200 tons capacity – models.
- A perfect choice for bridge/building lifting, shipyard use, utility and mining maintenance use.
- Aluminum overlay bearings provide quality and long cylinder life.
- Chrome plated plunger resists corrosion.
- Grooved design in plunger load cap saddle helps reduce load slippage.
- 9796 Quick disconnect couplers included in the ‘Advance’ and ‘Retract’ ports.
- Built in safety relief valve prevents over pressurization of the retract circuit.
- Engineered collar thread, plunger thread and base mounting holes are standard on all models.
