BVA Hydraulics Custom Electric Hydraulic Pumps

All BVA Hydraulics products are designed, manufactured, and tested to meet or exceed ISO 9001 standards.

Buffalo Hydraulic proudly serves as a Factory Authorized Distributor and a Factory Authorized Warranty/Service Center for all BVA Hydraulics components.

Spec Sheet
Inquire About This Product

Add to Wishlist
Categories: ,
Description

BVA Hydraulics PE50W4L25A Custom Electric Hydraulic Pump

  • 10,000 P.S.I. Maximum pressure.
  • 476 cu.” Of oil per minute from 0 – 700 p.s.i. (1st Stage).
  • 61 cu.” Of oil per minute from 701 – 10,000 p.s.i. (2nd Stage).
  • 115 VAC, 1 Ph., 60 hz.
  • 25 Gallons (5,775 cu.”) of useable oil volume.
  • Internal relief valve.
  • 4-Way, 3-Position Manually operated directional valve.
  • 10′ Hand-held motor control pendant.
  • Equipped with N.I.S.T. certified, glycerin-filled 0-10,000 psi pressure gauge.
  • 476 cu.” Of oil per minute from 0 – 700 p.s.i. (1st Stage).
  • (4)  Optional, heavy industrial, sealed bearing caster assemblies installed.
