BVA Hydraulics HDG10004 High Tonnage Hydraulic Cylinders

Spec Sheet
Inquire About This Product

Add to Wishlist
Categories: ,
Description

BVA Hydraulics HDG10004 High Tonnage Hydraulic Cylinders.

  • 10,000 psi maximum operating pressure.
  • Double-acting design.
  • 102.86 Tons force – Advance.
  • 47.93 Tons force – Retract.
  • 9.13″ Retracted height.
  • 3.94″ Stroke/Travel.
  • Pressure relief valve on the Retract portion.
  • 74 lbs.

The BVA Hydraulics HDG Series of double-acting cylinders are offered in 35 models with capacity ranges of 100 – 1,000 tons capacity.

All BVA hydraulic cylinders are designed, manufactured, and tested to ASME B30.1 criteria.
