BVA Hydraulics PE50S4N05A, 10,000 psi Electric-Hydraulic Pump

BVA Hydraulics PE30, PE40, and PE 50 Series of 10,000 psi electric-hydraulic pumps offer an endless variety of options and configurations.

Buffalo Hydraulic proudly serves as a Factory Authorized Distributor as well as a Factory Authorized Warranty/Service Center for all BVA Hydraulics products.  This close working team approach will provide you with any and all technical support you require, before, during your purchase, and after your electric-hydraulic pump is in use – Please call today and let us know how we can help in support of your high-pressure hydraulic project!



Spec Sheet
Inquire About This Product

Add to Wishlist
Categories: ,
Description

BVA Hydraulics PE50S4N05A, 10,000 psi Electric-Hydraulic Pump

  • 10,000 psi Maximum pressure.
  • 120 VAC, 1 Ph., 60 hz. operating voltage.
  • High flow, 2- stage design.
  • 475 cu.” of oil per minute at 700 psi (1st Stage).
  • 61 cu.” of oil per minute @10,000 psi (2nd Stage).
  • 4/Way, 3/position solenoid-operated, locking valve for superb pressure holding quality.
  • OSHA-approved sound level – 80 dBA.
  • 5 gallons (1,155 cu.”) oil reservoir.
  • 24V hand-held motor control pendant.
  • Internal relief valve set at 10,000 psi.
  • 100% Duty cycle, NEMA 5 enclosure TEFC motor.
  • Shown, equipped with an optional NIST Certified pressure gauge with maximum indicator pointer.
