Power Team PE554 10,000 PSI Electric Hydraulic Pump

The Power Team PE 55 Series of electric hydraulic pumps offers a rugged design for use with 10,000 psi applications of bending, crimping, cutting, jacking, lifting, pressing, shearing, straightening, stressing, tensioning and torquing.

Spec Sheet
Inquire About This Product

Add to Wishlist
Category:
Description

Power Team PE554 Electric Hydraulic Pump

  • Internal relief valve set to bypass at 10,000 psi.
  • 115 VAC and 230 VAC, 1 Ph., 50/60 Hz.
  • 25 amps at 10,000 psi with 115 VAC models, 15 amps with 230 VAC models.
  • 704 cu.” of oil per minute at start up to 55 cu.” per minute @10,000 psi (2nd Stage).
  • 4/way, 3/position manually operated, shear seal directional valve with Posi-Check feature for increased pressure/load holding quality (shown).
  • 10′ hand held motor control pendant.
  • 2 1/2 gallons oil reservoir – 10 gallons option available on all models.
