BVA Hydraulics 200T Electric Hydraulic Double Acting Lifting System

BVA Hydraulics HDG Series of high tonnage, hydraulic jacking cylinders are offered through (35) standard models ranging from 100 – 1,000 tons capacity.

All BVA Hydraulics cylinders are designed, manufactured, and tested in compliance with ASME B30.1 standards.

Spec Sheet
Inquire About This Product

Add to Wishlist
Categories: ,
Description

BVA Hydraulics  200T Electric Hydraulic Double Acting Lifting System

  • 10,000 psi maximum operating pressure.
  • 400,000 lbs. force (Advance) at 9,759 psi.
  • Double-acting design.
  • 11.81″ Stroke/travel.
  • ø 5.31″  Industrial hard chrome plunger.
  • ø 7.24″ Precision burnish rolled internal bore.
  • ø 9.25″ Outside diameter.
  • 322 lbs.
  • Rod-end relief valve standard on all HDG Series cylinders.
  • Advance and retract quick disconnect couplers are included and installed on all models.
  • Engineered lifting eyes for positioning on the job site.
