BVA Hydraulics HDG50012, 500 Tons Capacity, Double-Acting, Hydraulic Jacking Cylinder

BVA Hydraulics  HD Series 10,000 psi single-acting and HDG Series 10,000 psi, double-acting hydraulic cylinders begin with high tensile gun drilled solid bar, industrial hard chrome plated plungers, high-grade urethane seals, and one-piece alloy bearings.  The component quality and machining throughout all BVA Hydraulics cylinders ensures that they are designed and manufactured to meet or exceed ASME B30.1 standards.

With standard models ranging from 100 – 1,00 tons capacity, the HD and HDG Series of 10,000 psi hydraulic cylinders offer durability and a great variety to choose from.



Spec Sheet
Inquire About This Product

Add to Wishlist
Categories: ,
Description

BVA Hydraulics HDG50012, 500 Tons Capacity, Hydraulic Jacking Cylinder

    • 10,000 psi maximum operating pressure.
    • 1,132,500 lbs. force – 566.25T (Advance) at 10,000 psi.
    • Double-acting design.
    • 11.81″ Stroke/travel.
    • ø 9.76″  Industrial hard chrome plunger.
    • ø 12.01″ Precision burnish rolled internal bore.
    • ø 15.75″ Outside diameter.
    • 1,321 lbs.
    • Rod-end relief valve standard on all HDG Series cylinders.
    • Advance and retract quick disconnect couplers are included and installed on all models.
    • Engineered lifting eyes for positioning on the job site.
    • 35 Standard HG Series, single-acting jacking cylinders ranging from 100 – 1,000 tons capacity.
    • 35 Standard HDG Series, double-acting jacking cylinders ranging from 100 – 1,000 tons capacity.
