Power Team R20010D Double Acting Hydraulic Jacking Cylinders
The R-Series of Power Team high tonnage hydraulic jacking cylinders offer a great variety from 100 – 565 tons of force.
- R20010D is shown and generates 413,000 (206.5T) each at 10,000 psi.
- 16.14″ Retracted height.
- 10.00″ Stroke/travel.
- Double acting (Advance/Retract).
- 10,000 psi maximum operating pressure.
Inquire about Power Team R20010D Double Acting Hydraulic Jacking Cylinders
Power Team R20010D Double Acting Hydraulic Jacking Cylinders
- R Series double-acting, high tonnage hydraulic jacking cylinders.
- 20 Standard models ranging from 100 – 565 tons of lifting force.
- Swivel load saddles are standard on all models to help reduce side load effects.
- Hard chrome plungers.
- Built-in relief valve to prevent over-pressurization on retract.
- Quick disconnect couplers are included on all models.
